> A qualified person must install the unit in accordance with all national and local code and ordinances (NFC - 15 - 100).
> Power supply wires must be such a certification YZW, and shall not be lighter than code designation 60245 IEC 57.
> An electrical circuit exclusive to the heat pump must be used as the power supply.
> The supply voltage, size of over current protective device, and size of supply conductors for the heat pump
are shown below.
> The Heat Pump Pool Heater condensing unit must be connected to a properly grounded electrical supply.
Do not fail to properly ground this unit.
> Check local electrical codes and regulations before obtaining wire.
> Use copper supply wires only.
Heat pump pool heater _11
ELECTRICAL SPECIFICATIONS
Electrical Specifications
80HPRA-E
100HPRA-E
