Compex MicroHub /6 TP1006C - Introduction to Compex MicroHubs; Hub Features Overview

English Compex MicroHub

/6 (TP1006C);
Compex MicroHub

/8 (TP1008C);
Compex MicroHub

/16 (TP1016C/ TP1016F)
1
“Quick Install Guide”
♦♦ Compex MicroHub

/6, 6-Port RJ-45
Ethernet Hub (TP1006C);
♦♦ Compex MicroHub

/8, 8-Port RJ-45 + BNC
Ethernet Hub (TP1008C);
♦♦ Compex MicroHub

/16, 16-Port RJ-45 +
BNC/AUI/Fiber Optic**
Ethernet Hub (TP1016C/ TP1016F**)
±±
Introduction
The Compex MicroHub

/8 (TP1008C); Compex MicroHub

/6 (TP1006C); and Compex
MicroHub

/16; (TP1016C/ TP1016F) are multi-port Ethernet hubs that bring unmatched
flexibility to LAN environments. There are multi-wiring connections for up to 6 (TP1006C);
or 8 (TP1008C); or 16 (TP1016C/TP1016F) UTP ports. In addition, there is: a BNC
(TP1008C); or a BNC/AUI (TP1016C); or a Fiber Optic (TP1016F) port for easy, direct
connection to different LAN media segments. The TP1006C/TP1008C;/ TP1016C/TP1016F
hubs constantly monitor each port for signal quality and will automatically disconnect a device
producing noise or excessive collisions. The disconnected device will be reconnected
automatically when the error condition is cleared.
±±
Hub Features (see diagrams on inner cover & page 13)
••
Power LED
♦♦ ON indicates hub is receiving power.
‚‚
Collision LED
♦♦ BLINKS to indicate collision of transmitted
packets occuring.
ƒƒ
Link/Activity LED
(TP1006C/TP1008C/TP1016C/
TP1016F)
♦♦ STEADY LIGHT indicates a good cable link
between adapter and hub;
♦♦ BLINKS to indicate network activity present.
„„
Jabber LED
(TP1016C/TP1016F)
♦♦ BLINKS to indicate transmission of packet/s
exceeding the specified time.
……
Uplink Button (TP1016C):
(TP1006C/TP1008C):
♦♦ Uplink mode when button is released OUT.
♦♦ Uplink mode (button shift Left).
††
6 RJ-45 Ports (TP1006C) ;
8 RJ-45 Ports (TP1008C) or
16 RJ-45 Ports (TP1016C/F)
♦♦ Configurable as 6; /8; / 16 UTP ports or 5; /7; /
15 UTP ports plus 1 UTP Uplink Port (Port #1).
‡‡
1 BNC;/ 1 BNC-1 AUI;/
1 BNC-1 Fiber Optic Port;
♦♦ BNC or AUI or Fiber Optic for connection to a
different LAN media segment.
ˆˆ
DC Power Socket
(TP1006C/TP1008C);/
AC Power Socket
(TP1016C/ TP1016F)
♦♦ Jack for connection to an external Output
Power adapter (DC 7.5V @ 1 Amp);
♦♦ Flexible power input (range 90VAC to
250VAC) meets every country requirement.
‰‰
ON/OFF Power Switch
(TP1016C/TP1016F)
♦♦ Provides a convenient means to power-up or
shutdown the hub.
