Computronic Q4M - Technical Specification

TECHNICAL SPECIFICATION
Q4M/Q8M
9
PICTURE PARAMETERS
TV standard:
CCIR / EIA
Number of the active TV lines:
512 / 480
Samples per TV line:
864 / 856
Gray scale:
256
VIDEO INPUTS
Number:
4 (8 by Q8M)
Amplitude:
0,75 - 1,5 V
p-p
Input impedance:
75 
Connectors:
BNC
VIDEO OUTPUTS
Number:
2 individual
Standard:
CCIR / EIA
Amplitude:
1 V
p-p
load 75 
Connector:
BNC
ALARM INPUTS
Number:
4 (8 by Q8M)
Loop connection:
input – ground (GND)
Activity:
normally open
Maximum alarm loop impedance:
1 k
Connector:
CANNON 25 pin socket
ALARM OUTPUT
Output:
2 low voltage relay contacts
Maximum switching voltage:
40 V
Maximum switching current:
0,5 A
TEMPERATURE CONDITIONS
Range of operating temperatures:
0 – 40 C
Humidity:
max. 85 %
POWER SUPPLY
Input voltage:
12 VDC
Power consumption:
max. 4 W
Connector:
Concentric 5,5 × 2,1 mm
MECHANICAL PARAMETERS
Dimensions:
218(W) × 44,5(H) × 230(D) mm
Weight:
1,4 kg
ACCESSORIES
Alarm connector mate + cover:
1 p
