Concept Pro H.264 - Appendix D: Technical Specifications


##!+&#'"!&
MODEL
Operation
Video in
Audio in
Main displays
Spot displays
Audio out
External alarm
User interface
Recording
Playback
Archiving
Time
PTZ
System
Network
Remote Access
Storage
Event handling
Security
Physical
Genuine Pentaplex
Channels
Connection
Loop through
Channels
Connection
BNC
VGA
S-Video
HDMI
Screen display modes
Sequence
Digital zoom
Channels
Connection
Display mode
Channels
Connection
Inputs
Outputs
On-screen display
Control
Video CODEC
Resolution options for each channel
Maximum total frame rate
Image quality
Pre-event recording
Recording modes
Frame rate options for each channel
Schedule
Configurable recording time limits
Audio
Motion detection
Covert recording
Camera title
Speed
Control
Search method
Split screen display modes
Audio synchronization
Storage
Format
Archive data
Time zone
DST
Time synchronisation
RS-485
Watchdog
Abnormal shutdown detection
HDD Error detection
System data backup / restore
Connection
Simultaneous connections
DHCP
DDNS
Two way network audio
Bandwidth management
I.E Browser
Remote configuration
Remote PTZ control
Email event notification
Maximum Capacity
Storage
Recording options
Source
Action
User levels
Key Lock
Dimensions
Weight
VXH264-16
Simultaneous recording, playback, network live view, network playback,
network remote set-up. Frame rate unaffected
16
BNC, 1.0Vpp composite 75ohm unbalanced
BNC, 1.0Vpp composite 75ohm unbalanced, auto-termination
4
RCA, line level unbalanced
1.0Vpp composite 75ohm unbalanced
15 pin D-SUB 1024 x 768 @ 60Hz
4 pin mini din Y/C
Single HDMI Socket. Max. 1024 x 768 @ 60Hz
1, 4, 6 (1+5), 8 (1+7), 9, 16
Adjustable dwell time, user-defined sequences
Between 2x & 14x
4, fully programmable
BNC, 1.0Vpp composite 75ohm unbalanced
Full screen sequence, adjustable dwell-time
1
RCA, line level unbalanced
16, NO or NC common ground
16, high (+5V) or low (0V) selectable,common ground + 4 Relay Out
GUI
Mouse, Front panel, IR Remote and / or VA-KBDPRO+ PTZ Keyboard
H.264
CIF (352 x 288), 2 CIF (704 x 288), D1 (704 x 576)
400 FPS (CIF)
Super, Highest, High, Standard, Low
5 seconds max
Schedule / motion detection / alarm / panic
25 - 13 - 7 - 3 - 2 - 1 - 0
Per channel, per hour, per day / week
12 hours, 1 day, 2 days, 3 days, 4 days, 5 days, 6 days,
1 week, 2 weeks, 3 weeks, 1 month, 2 month
Audio inputs independently assigned to each channel
16 x 16 selectable grid with 10 levels of sensitivity
Yes, selectable by channel
8 characters (max)
Forward / reverse. 1x, 2x, 4x, 8x, 16x, 32x, 64x
Front panel buttons and Jog / Shuttle ring, mouse
Calendar / timeline, event log, instant playback, Pano
1, 4, 16
Yes, any frame rate
CD-R (DVD±R option), USB Memory stick, Network
Watermarked AVI
Independent channel selection, back-up log, event log
Worldwide, selectable
Yes
Internet time server
Multi-protocol, baud rate and speed control for each channel
Yes
Yes, with system auto recovery
Yes, SMART monitoring
Yes, USB memory stick
RJ45
4 (max)
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Currently 8TB
4 x HDD maximum
Stop when full / overwrite
Alarm in, motion detection, video loss, HDD error, Panic
Record, alarm out, email notification, log, remote client pop-up,
buzzer, full screen pop-up
ADMIN, MANAGER*, USER* (*Configurable)
Yes, password protected
428mm(w) x 475mm(d) x 93mm(h)
4.8kg (without HDD)
