Page #7 background imageLoading...
Page #7 background image
FRANÇAIS
ENGLISH
ESPAÑOL
ENGLISH
ESPAÑOL
FRANÇAIS
7
FRANÇAIS
ENGLISH
ESPAÑOL
ENGLISH
ESPAÑOL
FRANÇAIS
PARTS LIST
PART No. DESCRIPTION
MS100-1 Table extension
MS100-2 Rubber foot
MS100-3 Base
MS100-4 Screw
MS100-5 Butterfl y screw
MS100-6 Table steel fl ake
MS100-7 Scale
MS100-8 Rivet
MS100-9 Table washer
MS100-10 Lock washer
MS100-11 Pan hd screw
MS100-12 Steel ball
MS100-13 Spring
MS100-14 Cap
MS100-15 Screw
MS100-16 Pan hd screw
MS100-17 Rubber circle
MS100-18 Pan hd screw
MS100-19 Hex hd screw
MS100-20 Small guide stem
MS100-21 Bearing
MS100-22 Slideway
MS100-23 Pan hd screw
MS100-24 Flat washer
MS100-25 Rubber base
MS100-26 Handle
MS100-27 Flange
MS100-28 Ring
MS100-29 Pan hd screw
MS100-30 Screw
MS100-31 Kerf board
MS100-32 Pan hd screw
MS100-33 Pointer
MS100-34 Rotating table
MS100-35 Fence
MS100-36 Flat washer
MS100-37 Lock nut
MS100-38 Rail lock
MS100-39 Lock washer
MS100-40 Hex soc hd screw
MS100-41 Knob
MS100-42 Butterfl y screw
MS100-43 Clamp
MS100-44 Rail
MS100-45 Wiper
MS100-46 Wiper cover
MS100-47 Lock washer
MS100-48 Pan hd screw
MS100-49 Rubber ring
MS100-50 Lock button
MS100-51 Spring
MS100-52 Hex soc hd screw
MS100-53 Nut
MS100-54 Hex hd screw
MS100-55 Bracket
MS100-56 Pivot shaft
MS100-57 Direction board
MS100-58 Pointer
MS100-59 Split pin
MS100-60 Slide bar seat
MS100-61 Screw
MS100-62 Flat washer
MS100-63 Adjusting handle
MS100-64 Nut
MS100-65 Mitre scale
MS100-66 Spring post
MS100-67 Spring stand
MS100-68 Compression spring
Please refer to the schematic drawing on page 15
PART No. DESCRIPTION
MS100-69 Baffl e
MS100-70 Plate
MS100-71 Plate
MS100-72 Screw
MS100-73 Screw
MS100-74 Spring
MS100-75 Lower guard
MS100-76 Flat washer
MS100-77 Pan hd screw
MS100-78 Screw
MS100-79 Screw
MS100-80 Link
MS100-81 Socket wrench
MS100-82 Screw
MS100-83 Outer fl ange
MS100-84 Saw blade
MS100-85 Ring
MS100-86 Inner fl ange
MS100-87 Bearing
MS100-88 Arbor
MS100-89 Woodruff key
MS100-90 Bearing
MS100-91 Bearing housing
MS100-92 Gear
MS100-93 Ext. Retainer ring
MS100-94 Bearing
MS100-95 Upper guard
MS100-96 Compression spring
MS100-97 Rubber
MS100-98 Locking ring
MS100-99 Bearing
MS100-100 Armature
MS100-101 Carbon brush
MS100-102 Bearing
MS100-103 Fan baffl e
MS100-104 Screw
MS100-105 Stator
MS100-106 Wire
MS100-107 Shield lock shelf
MS100-108 Screw
MS100-109 Fixed shield
MS100-110 Spring
MS100-111 Ext ret ring
MS100-112 Rubber jacket
MS100-113 Locking pin
MS100-114 Label
MS100-115 Hex hd screw
MS100-116 Dust chute
MS100-117 Dust bag
MS100-118 Flat washer
MS100-119 Lock washer
MS100-120 Pan hd screw
MS100-121 Brush cap
MS100-122 Brush holder
MS100-123 Motor housing
MS100-124 Spec label
MS100-125 Handle
MS100-126 Capacitor
MS100-127 Inductor
MS100-128 Switch
MS100-129 Cable clamp
MS100-130 Screw
MS100-131 Cable jacket
MS100-132 Cord
MS100-133 Handle mount
MS100-134 Carry handle
MS100-135 Screw
