PLACING & MOUNTING
7
1. Placing
When placing the media center in any type of enclosed space, be sure to allow space
around it for ventilation.
If placing in a tight space without ventilation, heat generated from the unit could produce
a potential heat hazard.
2. Mounting
Rough opening cut-out
about 140mm (5 5/8 in )
(WMS-DVDZ3-SB)..................................................28 3/4(Width) x 3 3/4(Height) x 5 5/8(Depth) in
(WMS-DVDZ3)........................................................10 5/8(Width) x 3 3/4(Height) x 5 5/8(Depth) in
about 140mm (5 5/8 in )
To Next Page
