DELTA II FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK OIPB – C15008
10
PARTS LIST – DELTA II
Item #
Part #
Description
Quantity
1
70-23-14-50
Rubber Sealing
1.00
3
14-17-10-05-N
Tool Bracket
2.00
5
90-25-10-01
Rubber Coupling
2.00
7
14-10-10-06
Spacer
2.00
9
14-17-10-08
Bracket for Coupling
2.00
10
14-17-10-04
Bottom Lid Bearing Housing
2.00
11
14-10-49-01
Bracket for Disc round
2.00
13
61-20-62-07
Bearing
4.00
14
14-17-10-02
Bearing Housing
2.00
15
14-17-10-01
Axis
2.00
19
14-17-10-03
Top Lid Bearing Housing
2.00
21
14-10-01-00
Machine Frame
1.00
22
70-25-01-70
Dust Hose
1.00
23
70-40-8M-50
Pulley Bearing Housing
2.00
24
61-20-60-04
Bearing
2.00
25
90-24-20-12-30
Taperlock
2.00
26
70-26-8M-50-U
Reverse Pulley
1.00
27
70-24-13-60
Belt
1.00
29
70-26-8M-50-38
Motor Pulley
1.00
31
14-10-02-00
Belt Cover
1.00
33
14-10-11-10
Lift Arm
1.00
35
61-50-10-41
Eye Screw
1.00
37
14-10-07-01
Swing Rear Axis
1.00
39
14-10-08-05
Axis
1.00
41
60-30-10-50
Cross Handle Screw
2.00
43
80-52-22-55
Wheel
2.00
45
60-33-12-25
Pin for lifting Rod
1.00
47
60-32-20-04
Spindel Pipe
1.00
49
14-10-04-01
Lid
1.00
52
18-10-05-02
Threaded Spindle
1.00
53
14-10-09-03
Spacer for Spindle
1.00
54
90-21-95-50
Level Adjustment Wheel
1.00
56
90-21-95-51
Knob for Handwheel
1.00
58
14-10-11-01
Bracket for Lift Pipe
2.00
59
14-13-11-03
Lifting Rod
1.00
