PRODUCT SPECIFICATIONS
PAGE 2
Item Description
VAC
Electrical Requirements
VDC
Electrical Requirements
Current Output: 12 VDC @ 10 AMP's
Voltmeter Equipped 0-150 Volts (50 Volt Increments)
Display Lights Red (Run)
Gasoline Engine
Fuel Tank Capacity 5.60 Gallons (25 Liters) / Includes Fuel Gauge
Estimated Run Time 9.0 Continuous Operating Hours
Approx. Weight 181 Pounds
This product requires oil and fuel to be added before starting. Attempting to
start the engine without oil WILL ruin the engine and void the warranty.
BEFORE starting the engine, refer to the engine owner’s manual for engine
maintenance information.
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, operating, inspec-
tion, maintenance and cleaning procedures, parts list and assembly diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front cover.
Keep this manual and invoice in a safe and dry place for future reference.
CAUTION: THIS GENERATOR IS NOT INTENDED TO POWER SENSITIVE ELECTRONIC
EQUIPMENT (INCLUDING MEDICAL EQUIPMENT) WITHOUT THE ADDITION OF AN APPROPRIATE
LINE CONDITIONER (SOLD SEPARATELY).
13 HP / Unleaded Gasoline Powered
Recoil Start / 4-Cycle OHV Air cooled
389 CC Displacement / 3600 RPM
1.05 Quart (1.0 Liter) Oil Capacity
EPA Approved
120 Volts 60Hz @ 47 AMPs Current Output
240 Volts 60Hz @ 23 AMPs Current Output
Continuous/Rated Wattage: 6,000
Peak Wattage: 8,000
Two 120V Outlet, One 240 Twist Lock Outlet
Generator Type
Brushless / Revolving Field / Self Exciting
Two Pole / Single Phase
One 47 AMP circuit breaker, One 23 AMP circuit breaker
