CONTROL PANEL ANALOG AND DIGITAL INPUTS
The panel has one analog input and up to one digital input available to monitor other components,
senders or signals. These inputs can be used for a number of purposes including alarms and shut
downs.
Input
Heading
Default
Options
Connector
Pin
Analog 1
Function
Fuel Level
A
5
Digital 1
Normally
Open
Open / Closed
A
4
Function
None
Message
None
Check
Off
Off / Always / Run
Digital B2
Function
Throttle Up
Always
B
2
Digital B5
Function
Throttle Down
Always
B
5
