M100 FireGard
TM
Chain & Crank
02/11
Connection Chart
Terminals
Connection
Type
Line In
High Voltage
L1 & L2
Low Voltage
1 & 2
(24VDC or 24VAC)
Alarm Connection
3 & 4
Power Input
Connect
115VAC
Connect
24VDC or 24VAC
(Voltage supplied by FACP
or an UL listed power supply)
Connect FACP*
Alarm Dry Contact
High Voltage Alarm Signal
Connect Alarm Signal
115VAC
Do Not Connect
Jump
(Wire size min 18AWG)
Low Voltage Alarm Signal Do Not Connect
Connect Alarm Signal
24VDC or 24VAC
(Voltage supplied by FACP)
Jump
(Wire size min 18AWG)
*Note: FACP – Fire Alarm Control Panel.
