M100 FireGard
TM
Chain & Crank
02/11
SPECIFICATION
Input Power:
Not Supervised
Voltage Frequency Standby Alarm*
120VAC
50 Hz 0.3A 0.4A
60 Hz 0.3A 0.4A
24VAC
50 Hz 1.5A 1.8A
60 Hz 1.5A 1.8A
24VDC - 0.6A 1.2A
*Note: Amp value is during alarm condition with 1A load warning
connected.
Alarm Dry Contact Rating: 24VDC, 0.5A, Not Supervised
Alarm Door Close Warning:
24VDC @Max. 1A, Resistive, Special Application (see below),
Common, Not Supervised
Brake Release (Dry Contact):
Rating: 24VAC/VDC, 2A Max., Resistive Load, Common,
Not Supervised
Fuse: F1: 3A@250V, Slo-Blo Type
F2: 1A@250V, Fast-Act Type
z 24V input power can be 24VDC or 24VAC or 24VDC from an approved UL1481 regulated power
supply.
z 18-gauge wire recommended.
z For “Indoor Dry” location use only.
z Close warning power is provided for less than a minute. Any UL Listed audible or visual device
may be used if the 24VDC input is powered by a UL1481 regulated and power limited power
supply.
z Optional: Activation/connection of UL approved fusible links.
