tL1
The first menu item after changing to the
operating level (operating level 1)
-1-
Back to operating level (operating level 1)
oL1
The first menu item after changing to the
expanded configuration level
(operating level 2.1)
:2.1-
To the expanded configuration level (operating level 2.1)
P__
: 1
Password adjustable between 0 and 999
“: 1” = no password provided
Entry of password
W
E
(Password)
tST
C_0
A_0
F_0
d_0
b_0
Test program
C_1
A_1
F_1
d_1
b_1
Cooling request relay
“Off - On”
Alert relay
“Off - On”
Fan relay
“Off - On”
Defrost heating relay
“Off - On”
Buzzer
“Off - On”
(Test-Program)
Note:
The upper control button “>” is used to select the appropriate function. The selected function is
switched on and off using the lower control button "<". The test program serves the purpose of
checking the controller functions and system components. After 12 min. have elapsed without a
button being pressed, the control will reassume its last configured functions and return to the user
nID
The first menu item after changing to the
network level
(operating level 2.2)
:2.2-
To the Network level (operating level 2.2)
SUb
50.0
Setting ... bis 50 °C / 121°F
The setpoint temperature upperbound
Setpoint temperature upper bound
W
E
(Setpoint Upper Bound)
Setpoint temperature lower bound (Setpoint Lower Bound)
rST
nO
rtd
rbt
LFP
Back to the configurationlevel without
executing a function
Reset of all values in the statistics
level (control level 3)
Restart of the controller (parameters
and configuration are retained)
Loading of the factory settings (parameters
and configuration are lost)
Reset
(Reset)
cCF
°C
All temperature values are
displayed in Celsius (°C)
Temperature scale
(Config Celsius Fahrenheit)
W
E
cEE
OFF
On
Alert “ECO” “Off”
Alert “ECO” “On”
System monitoring
W
E
(Config ECO Enable)
Note:
The system monitoring provides early warning of system faults before the malfunction occurs and
protects goods against damage. By tracking the block temperature during the cooling process, a
performance reduction of the cooling plant is already detected in the beginning and signalled by the
alert “ECO”.
Note:
With “SLb” und “SUb” the adjustment range of the setpoint temperature under the item “tSr” can be
limited. In conjunction with the password “P__” a manipulation of the setpoint value (control level 1
under “tSr”) can be prevented.
SLb
:50.0
Setting -50°C / -58°F to ...
The setpoint temperature lowerbound
W
E
°F
All temperature values are
displayed Fahrenheit (°F)
bUC
On
Buzzer Control “On”
rEP
OFF
Buzzer Control “On”
with repetition
Buzzer Control “Off”
Buzzer Control
W
E
(Buzzer Control)
Buzzer Control “Off”
Buzzer remains disabled at all.
Buzzer Control “On” with repetition
The buzzer is switched “on” in the event of a fault. The buzzer becomes disabled by pressing one of
the buttons. If the fault is not cleared within two hours, the buzzer recurs.
Buzzer Control “On”
The buzzer is switched “on” in the event of a fault. After pressing one of the buttons, the buzzer is
disabled and remains disabled up to the next fault.
OFF
Alert in the event of power failure “Off”
W
E
PFC
On
Alert in the event of power failure“On”
Power failure control
(Power Fail Control)
Alert in the event of power failure“On”
After a power failure, the alert “PFL occurs.
Alert in the event of power failure“Off”
After a power failure, the alert remains disable.
Configuring the goods protection program is only possible in the case of electro- or
recirculating air defrost. In the case of recirculating air defrost the heating is done by an
additional heater.
Goods protection program on, following setpoint, with early low temperature
warning (FSL)
To protect goods from low temperature (e.g. otherwise resulting in freezing), the goods protection
program is initiated after the temperature has fallen below the actual setpoint, even if a setpoint
correction is configured. If the room temperature falls more than 0.5 K/0.9 °R below the setpoint, after
a maximum of 12 minutes the cooler fan is started. If the controller detects an ongoing negative trend
of the room temperature in a time window of 18 minutes, the heating is switched on additionally. At the
same time the low temperature warning "EGP" is displayed by the controller. If using hot gas defrost
(menu item "cd", "HGE" or "HGS") only the temperature is monitored, the defrost relay remains
unswitched.
Goods protection program on, with early low temperature warning (OnL)
In contrast to the previosly described procedure for the goods protection against low temperature,
now the lowest setpoint is relevant for the monitoring. Here the correction value must be paid
attention to, when setpoint correction is used. The further procedure is the same as described
previously ("cGP", "FSL").
Goods protection program on, following setpoint (FS)
See ("cGP", "FSL"), however without early low temperature warning. The low temperature warning
"EGP" is displayed, after the heating/heater remained on for at least 60 minutes without interruption.
Goods protection program on (On)
See ("cGP", "OnL"), however without early low temperature warning. The low temperature warning
"EGP" is displayed, after the heating/heater remained on for at least 60 minutes without interruption.
Goods protection program off (OFF)
Room temperatures below the setpoint are not monitored.
Note:
The setting "FSP" together with the setpoint correction "cSS" could also be used as an unfreezing- or
heating program. In the case of single sensor control ("cS","cSS") the goods protection program is
not taken into account.
Attention: When using defrost communication with the digital inputs 1 or 2, the goods protection
program should not be configured. Nonobservance results in the alert "EUS".
On
OFF
W
E
cGP
FS
ONL
FSL
Goods protection program “on”,
following setpoint
Goods protection program “on”
Goods protection program “off”
Goods protection program “on”,
with early low temperature warning
Goods protection program “on”, following
setpoint, with early low temperature warning
Goods protection program
(Config Goods Protection)
W
E
Factory setting (All temperature values of the factory setting are indicated in Celsius)
7
