COOL HEAD RC600 - Intended Use; Parts

GB
3
Intended Use
Parts
Freezer
14
13
15
1 2 3 4
9
10
11 12
5
6
7
8
Only use this appliance for cooling and storage of food and beverage for commercial purposes.
1.
Main switch (Optional)
2. Front panel
3. Lock
4. Controller
5. Pressure valve* (see remark)
6. Evaporator / shelf
7. Gasket
8. Door
9. Plug
10. Door support
11. Down panel
12. Door down hinge
13. Compressor
14. Condenser
15. Condenser fan motor only for 400L
Remark: It keeps the inside and outside pressure of the freezer in the
same level for easy door opening.
1 2 3 4
9
10
11 12
5
6
7
8
RN600
RN200
RN400
1 2 3 4
6
7
8
16
16. Handle
9
