Coolaroo FAIRHAVEN - Step 13: Securing First Louvre Arm

18
Figure 13.
STEP 13
Ensure the louvre arm (L) is in the correct position (as per illustration).
Re-insert the louvre bolt and tighten with the Allen key (X).
