TROUBLESHOOTING
CONTROLLER STATUS MODE LED STATUS LOAD BEHAVIOR
OFF (No Input Power) All OFF OFF
DMX Control Input
Recognized
All except
Standalone
Green ON Steady Responsive to DMX commands
Standalone Recognized Standalone
Alternate Amber/Green
Slow (1 Hz)
Responsive only to DIP switch setting
DMX Control Input missing All Amber On Steady State Full ON
DMX Shorted
All except
Standalone
Amber On Steady State Full ON
Input Over Voltage All Amber Flashing Slow (1Hz) OFF
Input Under Voltage All Amber Flashing Fast (8 Hz) OFF
Output Short Circuit V+ to V-
All, and DIM
voltage V<9.5V
Red Flashing with
Intermittent Green
Load is OFF on shorted Channel
All loads of the unit, except the shorted one, are flashing
The rest of units in the installation remain responsive to DMX
commands
Output Short Circuit V+ to V-
All, and DIM
voltage V>9.5V
Red Flashing with
Intermittent Amber
Load is OFF on shorted Channel
All loads of the unit, except the shorted one, are flashing
The rest of units in the installation remain responsive to DMX
commands
Output Short Circuit to V+
TNW/DTW Dim
Input Control
set to V<9.5V
Red Flashing with
Intermittent Green
Load is OFF on shorted Side of TNW Channel
All other loads of the unit, except the shorted one, are flashing
The rest of units in the installation remain responsive
to DMX commands
Output Short Circuit to V+
TNW/DTW Dim
Input Control
set to V>9.5V
Red Flashing with
Intermittent Amber
Load is OFF on shorted Side of TNW Channel
All other loads of the unit, except the shorted one, are flashing
The rest of units in the installation remain responsive to DMX
commands
Output Overload All Red Flashing
Overloaded channel dimmed and flashing at 1s constant rate
All other loads of the unit remain responsive to DMX commands
DMX Disconnected during
normal operation (D- or D+)
from unit “n”
All except
Standalone
Amber LED on units with
addresses > "n"
Units with addresses <n have loads flickering and units with
addresses >n are at full ON and display amber LED
D+ and D- reversed, from
unit “n”
All except
Standalone
Amber LED on units with
addresses > "n"
Units with addresses <n have loads flickering, but responsive to
DMX cmd
Units with addresses >n put their loads at full ON
D+ and GND shorted at unit “n”
All except
Standalone
Amber LED on units with
addresses > "n"
Units with addresses <n have loads responsive to DMX
commands
Units with addresses > n have loads at full ON
D- and GND shorted at unit “n”
All except
Standalone
Amber LED on units with
addresses > "n"
Units with addresses <n have loads responsive to DMX
commands
Units with addresses > n have loads at full ON
WARNING:
Each module treats the input controls available with the following priority:
1. Standalone (Fixed or Dynamic): If DIP Switch setting for one of these modes is
selected, the module will ignore DMX control input and operate according to
the settings of the operational mode selected
