A. USING 2.4 GHZ - AN OVERVIEW
If the physical switch is toggled to Bluetooth or 2.4 GHz Mode
Please charge your new keyboard for at least 2 hours before using for the first time.
IMPORTANT
1. Toggle the physical switch on the side of the keyboard to enter Bluetooth Mode.
2. Press and hold FN + DEL/PGUP/PGDN for 5 seconds to enter pairing mode. The
indicator will rapidly flash BLUE 3 times one every second to confirm you are in
Pairing Mode.
3. If pairing is successful, the indicator will light up with a solid WHITE light for 3
seconds. If unsuccessful, the keyboard will enter Sleep Mode after 30 seconds. In
Sleep Mode, all the keyboard lighting will be turned off.
1. When the Bluetooth mode is activated, the keyboard will connect to the previous
synced wireless device (DEL/PGUP/PGDN) automatically within seconds.
2. If successfully connected, the indicator will light up with a solid WHITE light for 3
seconds. If unsuccessful, the keyboard will enter Sleep Mode after 30 seconds. In
Sleep Mode, all the keyboard lighting will be turned off.
3. To connect to a specific paired device, press FN + DEL/PGUP/PGDN after activating
Bluetooth mode to connect to the corresponding device. The keyboard will connect
to the device if successful and enter sleep mode after 30 seconds if device is not
found or fails to connect.
1. Toggle the physical switch on the side of the keyboard to enter Bluetooth Mode.
1. Press FN + DEL/PGUP/PGDN to switch to the corresponding paired device.
2. Press and hold FN + DEL/PGUP/PGDN for 5 seconds to enter pairing mode. The
indicator will rapidly flash BLUE 3 times one every second to confirm you are in
Pairing Mode.
3. If pairing is successful, the indicator will light up with a solid WHITE light for 3
seconds. If unsuccessful, the keyboard will enter Sleep Mode after 30 seconds. In
Sleep Mode, all the keyboard lighting will be turned off.
2.4 GHz MODE
INDICATOR LIGHT RULE
CHARGING
WIRED MODE
BLUETOOTH MODE
4. To pair with other devices, simply unplug the dongle and re-plug
into another device. If pairing is successful, the indicator will light up
with a solid WHITE light for 3 seconds. If unsuccessful, the keyboard
will enter Sleep Mode after 30 seconds. In Sleep Mode, all the
keyboard lighting will be turned off.
3. If successfully connected, the indicator will light up with a solid
WHITE light for 3 seconds. If unsuccessful, the keyboard will enter
Sleep Mode after 30 seconds. In Sleep Mode, all the keyboard lighting
will be turned off.
2. Plug the included dongle into the desired device. The keyboard
should automatically connect to the device.
1. Toggle the physical switch on the side of the keyboard to enter 2.4
GHz Mode. The indicator will continuously flash a BLUE light one every
second to confirm it is trying to connect to a device.
1. Toggle the physical switch on the side of the keyboard to enter 2.4 GHz
Mode. Press and hold FN + Enter for 5 seconds to enter pairing mode. The
indicator will rapidly flash BLUE 3 times one every second to confirm you are
in Pairing Mode.
2. Plug the included dongle into the desired device. The keyboard should
automatically connect to the device.
3. If pairing is successful, the indicator will light up with a solid WHITE light
for 3 seconds. If unsuccessful, the keyboard will enter Sleep Mode after 30
seconds. In Sleep Mode, all the keyboard lighting will be turned off.
B.MANUALLY PAIRING 2.4 GHZ DONGLE
TO THE KEYBOARD
The keyboard will switch to Wired Mode automatically as it is connected
to a PC or laptop.
If the physical switch is toggled to Wired Mode
The keyboard will switch to Wired Mode automatically as the physical
switch is toggled to Wired and it is connected to a PC or laptop.
Turning On Bluetooth for the First Time
Turning On Bluetooth After the First Time
The keyboard will begin charging when it is plugged into a PC, laptop, or
power source. The indicator light will be RED when charging and change
to GREEN when battery level is full.
The CAPSLK indicator will light up with a solid WHITE light when turn on
CAPSLK key, and turn off when turn off CAPLSK key.
*In Wired Mode, the indicator will change to GREEN for 3 seconds then
turn off when the battery level is full.
When the keyboard is plugged into a PC, laptop, or power source, the
indicator will show a RED light when charing and change to GREEN when
battery level is full.
Press FN will show the pairing status of each location (DEL, PGUP or
PGDN) with WHITE light.
1. In Pairing Mode, the indicator will rapidly flash BLUE 3 times one every
second.
2. In Connecting Mode, the indicator will continuously flash a BLUE light
one every second.
3. If Pairing / Connecting is successful, the indicator will light up with a
solid WHITE light for 3 seconds.
1. When the battery level falls below 15%, the indicator will rapidly flash
RED light 3 times every 20 seconds. This indicator lighting will repeat
until the keyboard enter Sleep Mode or is connected to the PC, laptop or
power source.
*The Low Power Mode percentage can be customized via Cooler Master
software.
2. When the battery level falls below 5%, the keyboard will go into Deep
Sleep Mode. All lighting will be turned off - including the indicator.
If the physical switch is toggled to Wired Mode
The keyboard will remain connected to the wireless device and begin charging
when it is plugged into a PC, laptop, or power source. The indicator light will be
RED when charging and change to GREEN when battery level is full.
If the physical switch is toggled to Bluetooth or 2.4 GHz Mode
SWITCHING TO WIRED MODE
CHARGING THE KEYBOARD
A. CAPSLK Indicator
B. Wireless Mode
C. Charging Status Indicator
D. Low Battery Scenario
E. Indicator on DEL/PGUP/PGDN
A. USING BLUETOOTH - AN OVERVIEW
B. MANUALLY PAIRING DEVICES
TO THE KEYBOARD
C. SWITCH PAIRED DEVICES
