6
cling of it. Do not burn the vacuum cleaner even if it is
badly damaged without removing the battery to avoid
the battery explosion.
•
Transport the unit in the original packaging only.
•
Keep the unit in a dry cool place out of reach of children
and disabled persons.
THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY. ITS
COMMERCIAL USAGE AND USAGE IN PRODUCTION AREAS
AND WORK SPACES IS PROHIBITED.
FUNCTION CAPABILITIES
Control and navigation in the mobile app
Control the unit, set up the cleaning modes and monitor the
operation process with COOLFORT mobile app.
BEFORE THE FIRST USE
After unit transportation or storage under cold (winter)
conditions, it is necessary to keep it for at least three
hours at room temperature before switching on.
•
Unpack the vacuum cleaner and remove any advertising
stickers and package materials.
•
Keep the original package.
•
Check the unit for damages, do not use it in case of
damages.
•
Read the safety instructions and the operation manual.
•
Make sure that operating voltage of the power adapter
corresponds to the voltage of your mains.
VACUUM CLEANER ASSEMBLY
Removal-installation of side brushes (2, 5) (Fig. 1)
•
Turn the vacuum cleaner over and insert the side brush-
es (2, 5) until they click.
•
The left side brush (5) has a green center, the right brush
(2) has a red one.
Note:
1. The right and left side brushes are not interchangeable.
2. After every use clean the brushes from dust and
garbage and, if necessary, wash them under warm
water jet.
•
To remove the side brush (2, 5), take it by the two drive
tangs and pull it up.
Removal-installation of the container
for collecting garbage and dust (11)
•
Open the upper lid of the robot (12) and remove the con-
tainer by the handle (27).
•
Remove the filter holder (23) together with the HEPA
filter (24).
•
There is a corresponding groove in the lid of the con-
tainer (25) to remove the filter holder.
•
Pull the HEPA filter (24) by the flag and remove it from
the holder (23)
•
Press the container lid lock (26) and open the container
lid (25).
•
A fine mesh is integrated into the container lid to retain
garbage and large particles.
•
Pay attention to the dust-proof valve (28) located inside
the container (11).
•
The valve (28) prevents dust and garbage falling out
when removing the container from the vacuum cleaner.
•
The valve should open and close freely without any jam-
ming.
•
Close the lid (25) of the container (11) until it clicks.
•
Insert the HEPA filter (24) back into the holder (23).
•
Insert the filter holder (23) back into the lid of the con-
tainer (25).
•
Place the assembled container (11) back into the robot
body and close the lid (12).
Installation of the charging station (32)
•
Install the charging station on a flat floor surface, against
the wall, the base of the charging station should be per-
pendicular to the floor.
•
The free space in front of the charging station should
be at least 1.5 meters, the free distance from the sides
of the charging station should be at least 0.5 meters
(Fig. 2).
•
Insert the plug of the power supply connection cord
(36) into the socket (35) at the charging station (32).
Carefully wind up the power supply connection cord, do
not allow it to hang down (Fig. 2, 3).
Note: Do not install the charging station near objects with
high reflectivity, for example, near mirrors, otherwise it
will be difficult for the vacuum cleaner to find the charging
station.
Removal-installation of the water tank (21)
To remove the water tank, press the key (22) and pull it out
of the robot body.
To install, insert it back into the body until it clicks (Fig. 4).
Removal-installation of the accessory
for wet floor cleaning (9)
(Used only in conjunction with the water tank (21))
•
Install the microfiber cloth (29) on the wet floor clean-
ing attachment (30) as follows: hold the cloth (29) with
the smooth side up, and the attachment (30) with touch
fasteners down, then insert the attachment into the
pocket of the cloth, pull the cloth slightly in the middle,
straighten the fabric around the edges and fix it with the
touch fasteners.
•
Install the assembled wet cleaning accessory (9) on
the water tank (21), to do this, align the two holes on
the tank with the fasteners on the attachment (30), as
shown in the figure (Fig. 5) by two arrows, then press
the attachment until it clicks. To remove the accessory,
press the attachment (30) in the direction away from
the tank (21).
•
To remove the microfiber cloth (29), pull it in the direc-
tion of the arrow as shown in the figure (Fig. 6).
BEFORE USING THE ROBOT
Warnings: Please refer to the following instructions to check
the cleaning area!
•
Remove all kinds of power cords, power extension cords
and other similar items from the floor that may interfere
with the movement of the vacuum cleaner.
•
The vacuum cleaner is designed to work on a smooth
floor or on a carpet with a low pile (less than 1 cm). Do
not use the vacuum cleaner for cleaning floors and car-
pets with high pile.
•
Make sure that there are no tablecloths, curtains or
other furnishings hanging to the floor along the path of
motion of the vacuum cleaner.
•
Make sure that there are no reflective surfaces in the
room, for example, mirrors or glasses which height from
the floor is less than 8.5 cm. If there are any, close them
or paste them over, otherwise it will affect the clean-
ing process.
•
The free space under the pieces of furniture should be
at least 8 centimeters, otherwise the vacuum cleaner will
simply get stuck under the furniture.
•
If the distance from the floor to the furniture is less than
8 centimeters, it is necessary to lift the furniture or to
provide a barrier from the vacuum cleaner getting in
such places.
•
When cleaning on stairwells, it is necessary to provide an
additional barrier for the vacuum cleaner.
