OPERATION AND MAINTENANCE MANUAL
120V/60HZ
BLIZZARD
AVALANCHE
GLACIER
CS518VD
CS518VDTB2
CS6361D
CS636VD
CS650VD

Questions and Answers

  • T
    Tina ThomasSep 3, 2025
    Why does CoolSpace Glacier CS5-18-VD-TB2 breaker trip when switch is turned on?
    • C
      courtneyfordSep 4, 2025
      If the breaker trips or the fuse blows when you turn on the switch of your CoolSpace Freezer, check the power cord length and breaker rating. Also, check for a locked-up pump. Refer to page 2 for unit amperage draw and to determine the required cord gauge. You might also need to replace the pump.
  • J
    Jason LutzSep 18, 2025
    What to do if CoolSpace Glacier CS5-18-VD-TB2 pump motor will not run when switch is turned on?
    • J
      John ThompsonSep 18, 2025
      If the pump motor of your CoolSpace Freezer will not run when the switch is turned on, and if the fan doesn’t start, check the breaker and cord plug-in. If the fan does start, check for power to and through the pump switch when turned on. Also, fill the water reservoir.
  • E
    ericfloresSep 16, 2025
    Why CoolSpace Freezer fan motor won’t run and makes a humming sound?
    • T
      Tara RodriguezSep 16, 2025
      If the fan motor of your CoolSpace Freezer won’t run and makes a humming sound, the blade might be in contact with the shroud, or the motor might be stalled. Re-center the blade hub and replace the motor.
  • J
    Jill SanchezSep 14, 2025
    Why CoolSpace Glacier CS5-18-VD-TB2 pump won’t run and power is available?
    • A
      Anthony PerezSep 14, 2025
      If the pump of your CoolSpace Freezer won’t run and power is available, ensure the switch is working. Also, check if the water level is high enough to activate the low-water cut-off circuit. Replace the switch if it's not completing the circuit and fill the water reservoir enough to activate the Low Water Shut-off switch.
  • R
    Richard GreerSep 12, 2025
    How to fix too many dry streaks in the CoolSpace Glacier CS5-18-VD-TB2 Freezer pads?
    • T
      Taylor Jones MDSep 12, 2025
      If you observe too many dry streaks in the pads of your CoolSpace Freezer, the holes in the spray bar might be blocked, or the water flow might need adjustment. Remove the spray bar, remove the plug, and clean the tube and holes. Then, open the water flow control valve.
  • J
    Joseph MccarthySep 12, 2025
    Why is water leaking from CoolSpace Glacier CS5-18-VD-TB2 Freezer water flow control valve?
    • C
      cindyhernandezSep 12, 2025
      If water is leaking from the water flow control valve of your CoolSpace Freezer, the washer or stem might be worn, or the jam nut or lock nut might be loose. Replace the water flow control valve and tighten the jam nut.
  • C
    Christine ReynoldsSep 9, 2025
    Why CoolSpace Glacier CS5-18-VD-TB2 fan will not reach speed but turns and makes humming sound?
    • H
      Hannah WrightSep 9, 2025
      If the fan of your CoolSpace Freezer will not reach full speed but turns and makes a humming sound, check the capacitor (where visible) and motor electrical connections. The extension cord might also be too small. Replace the capacitor or motor, and increase the cord gauge.
  • R
    rojashunterSep 7, 2025
    Why is water leaking from CoolSpace Glacier CS5-18-VD-TB2 Freezer drain valve?
    • J
      john24Sep 7, 2025
      If the water is leaking from the drain valve of your CoolSpace Freezer, it might be due to a worn washer or stem. Replace the washer, or replace the drain valve.
  • V
    vjohnsonSep 5, 2025
    How to fix CoolSpace Freezer fan that won't run?
    • M
      Matthew PattonSep 5, 2025
      If the fan of your CoolSpace Freezer won't run and makes no sound, reconnect the power or extension cord and reset the breaker.
  • D
    Derek MuellerAug 20, 2025
    What to do if CoolSpace Freezer unit overflows?
    • L
      larry03Aug 21, 2025
      If the CoolSpace Freezer unit overflows from the reservoir or spits water through the fan, first, tighten the connections or replace the hose washers. If the issue persists, reduce water pressure by adding an inline reducer. Also, inspect all hoses for leaks.

CoolSpace Glacier CS5-18-VD-TB2 Specifications

General IconGeneral
Power Supply115V, 60Hz
Defrost TypeManual
Energy Star CertifiedNo
Door LockYes
Reversible DoorNo
Capacity5 cubic feet
