ChargerandACTransferSection


ACInputSurgeProtection



‐ 175JMOVisconnectedacrosstheLineandNeutralofACInput

ChargerDCOutputOverVoltageShutdown



‐ BatteryOvervoltageprotection:16.0+/‐0.5Vdc(Errorcode:E10)
‐ AudioAlarm:Beep@1HzandACchargerislatchedoff
‐ Bypassmodeisavailable
‐ Toreseterrorcode,removeACInputandturnunitoffandon


DeadBatteryCharging

BatteryvoltagemustmeetthefollowingconditionsorErrorcodeE11willdisplay:


‐ Initialbatteryvoltagemustbe10Vorhigherforchargetocommence
‐ Ineventbatteryvoltagedropsbelow10Vafterchargeisinitiated(AddedLoad)
Maximumtimeforbatteryvoltagetoriseabove10VinBulkcharge:15minutes
‐ AudioAlarm:Beep@1HzandACchargerislatchedofffollowing15minutedelay
‐ Bypassmodeisavailable
‐ Toreseterrorcode,removeACInputandcycleunitoffandonuntilreset

ParametricDisplay


Thetwobuttonsonthedisplaypanelcanbeusedtoselectwhatisbeingdisplayedonthe
screenandtoenterintofeatureselectmode. Toselectwhatisbeingdisplayedonthe
screenduringinvertermode,press‘Select’buttontotogglethedisplaytoshowfollowing:


‐ DCInputVoltageinVdcwith‘InputVoltage’LEDOn
‐ ACOutputPowerinkWwithOutputPower’LEDOn
‐ Inverterfunctionsetting‘In0/1’withInputVoltageandOutputPowerLEDOff
‐ ChargercurrentsettinginAdc withInputVoltageandOutputPowerLEDOff
‐ Alarmfunctionsetting‘AL0/1’withInputVoltageandOutputPowerLEDOff
‐ Undervoltageshutdownsetting‘sdL/n/h’withInputVoltageandOutputPowerLED
Off
‐ BatteryType[FI]=Fixed,‘FLo’=Flooded,‘gEL’=Gel,‘Ag’=AGM



