Cooper Bussmann 1000W - Display and Diagnostics

41

Toselectwhatisbeingdisplayedonthescreenduringby‐passmode,press‘Select’button
totogglethedisplaytoshowfollowing:


‐ DCInputVoltageinVdcwith‘InputVoltage’LEDOn
‐ Inverterfunctionsetting‘In0/1’withInputVoltage/CurrentandOutputPowerLEDOff
‐ ChargercurrentsettinginAdc withInputVoltageandOutputPowerLEDOff
‐ Alarmfunctionsetting‘AL0/1’withInputVoltageandOutputPowerLEDOff
‐ Undervoltageshutdownsetting‘sdL/n/h’withInputVoltageandOutputPowerLED
Off
‐ BatteryType[FI]=Fixed,‘FLo’=Flooded,‘gEL’=Gel,‘Ag’=AGM


Toenterfeatureselectmode:


‐ Pressandholdthe‘Power’buttonforfivesecondstoenterintothefeatureselectmode.
‐ Press‘Power’buttontoselectfeaturebytogglebetweenCurrentsetting–‘Cur’ ,
Inverterdisable–‘In’,Alarmsetting–‘AL’,UnderVoltageshutdownsetting–‘Sd’and
Factorydefault‘dEF’.
‐ Oncethefeatureisselected,pressthe‘Select’buttontotogglebetweensetting:
‘Cur’:2A‐5A‐10A‐[20A](selectchargercurrentfor12‐110‐1000‐B2)
2A‐5A‐20A‐[40A](selectchargercurrentfor12‐110‐1000‐B4, 
12‐110‐1800‐B4)

‘In’: In0–[In1[(inverterdisable/enable)
‘AL’: AL0–[AL1](alarmdisable/enable)
‘Sd’: ShutdownlowSdL,Shutdownmid[Sdn],ShutdownhighSdH
‘bAt’:Batterytypeselect:[FI]=Fixed,‘FLo’=Flooded,‘gEL’=Gel,‘Ag’=AGM
(undervoltageshutdownLo/Hi)
‘dEF: Settofactorydefault(maximumchargercurrent,In1,AL1,Sdn,FI)
‐ Pressandhold‘Select’for5secondstomemorizethesettinganditwillautomaticallygo
tothenextfeaturesetting.Theusercancarryonthefeatureselectoritwill
automaticallyexitthefeaturesettingmode.Factorydefaultsareenclosedinbrackets[]
intheabovelist.




