Cooper B-Line CT02MAN - Appendix Sheet 11

55
Cable Tray Manual Cooper B-Line, Inc
CABLE TRAY INSTALLATION & SPECIFICATION CHECKLIST
Appendix Sheet 9
Material
Width
Aluminum ❏ 3” ❏
Pre-Galvanized Steel ❏ 4” ❏
Hot-Dip Galvanized Steel ❏ 6” ❏
304 Stainless Steel ❏ 8” * ❏
316 Stainless Steel ❏
* Fiberglass only.
Fiberglass-Polyester Resin ❏
Fiberglass-Vinyl Ester Resin ❏
Fitting Radius
Type 0” ❏
Ventilated ❏ 6” ❏
Non-Ventilated ❏ 12” ❏
24” ❏
36” ❏
Cable Channel
System Depth*
Data-Track ❏ Straight Rung ❏
Verti-Rack ❏ 2” ❏
Half-Rack ❏ 3” ❏
Multi-Tier Half Rack ❏ 4” ❏
6” ❏
Width* Rung Spacing* Tiers* Length
3” ❏ 6” ❏ 2 ❏ 120” ❏
6” ❏ 9” ❏ 3 ❏ 144” ❏
9” ❏ 12” ❏ 4 ❏
12” ❏ 18” ❏ 5 ❏
18” ❏ 24” ❏ 6 ❏
24” ❏
* Options shown are not available for all systems. Please check B-Line Cent-R-Rail Catalog for availability.
Cent-R-Rail
Width* Depth* Wire Mesh Size Length
2” ❏ 1” ❏ 2 x 4 118” (3 meters)
4” ❏ 2” ❏
6” ❏ 4” ❏
8” ❏
12” ❏
* Widths shown are not available for all depths.
18” ❏
Please check B-Line Wire Basket Catalog for availability.
24” ❏
Wire Basket Tray
