Cooper McGraw-Edison VR-32 - S225-10-10

S225-10-10
3
Figure 2.
External Features of the VR-32 Voltage Regulator
MOV-TYPE SERIES
ARRESTER
UPPER FILTER PRESS
CONNECTION
SHUNT ARRESTER
MOUNTING BOSSES
(3 PER BUSHING)
REGULATOR LIFTING LUGS
LASER-ETCHED
NAMEPLATES (2)
(SECOND ON CONTROL
ENCLOSURE DOOR)
BALL-TYPE OIL
SIGHT GAUGE
PANEL-TYPE RADIATORS
CONDUCTOR
STABILIZING BOSS
HANDHOLE COVER
COVER
AUTOMATIC
PRESSURE RELIEF
DEVICE
CONTROL CABLE WITH
DISCONNECT PLUG
LOCKABLE CONTROL
ENCLOSURE
CONTROL
POSITION INDICATOR
JUNCTION BOX
GROUND BOSSES (2)
DRAIN VALVE & OIL
SAMPLING DEVICE
BOLT-DOWN PROVISIONS (4)
CLAMP-TYPE CONNECTORS
THREADED-STUD
BUSHING TERMINALS
BUSHINGS
INTERNAL ASSEMBLY
LIFTING EYES
POLE MOUNTING
BRACKETS
