QD3 Quik-Drive V
oltage Regulator T
ap-Changer Manual
12
New Contacts
Figure 14.
QD3 moveable contact.
Figure 17.
QD3 stationary contact.
Intermediate Life Stage
Figure 15.
QD3 moveable contact.
Figure 18.
QD3 stationary contact edge.
End of Contact Life Stage
Figure 16.
QD3 moveable contact, end of life.
Figure 19.
QD3 stationary contact edge, end of life.
11
13
Table of Contents
Table of Contents
1
Safety Information
2
Product Information
3
Switch Arm
5
Installation
7
Part Kit Instructions
18
QD3/T350 Main Moveable Contact Assembly Kit
19
Kit Number 5741325B04 QD3/T350 Main Moveable Contact Assembly Kit
32
QD3/T350 Motor Replacement Kit
40
Kit Number 57A63675100B
46
QD3/T350 Motor Resistor Replacement Kit
46
Kit Number 5791844A01
46
QD3/T350 PI Drive Cam Replacement Kit
49
Kit Number 5740783B21
49
QD3/T350 Reversing Stationary
51
QD3/T350 Reversing Moveable Contact and
60
Kit Number 5741325B03
60
QD3/T350 TC-LTC P.I. Drive Face Gear Kit
72
Kit Number 5740787B11
72
QD3/T350 Quick Drive Holding Switch
74
