Cooper QD3 User Manual

S225-12-1
17
!
SAFETY
FOR LIFE
QD3/T350 Replacement Part Kit Pictures
Figure 27.
Main moveable contact assembly 5741325B04.
Figure 30.
Motor resistor replacement kit 5791844A01.
Figure 28.
Main stationary contact assembly 5791822A01.
Figure 29.
Motor replacement kit 57A63675100B.
Figure 31.
P.I. Drive cam replacement kit 5740783B21.
Figure 32.
TC-LTC P.I. Drive face gear kit 5740787B11.

Cooper QD3 Specifications

General

Brand	Cooper
Model	QD3
Category	Controller
Language	English
