QD3 Quik-Drive V
oltage Regulator T
ap-Changer Manual
8
Position Indicator
Drive T
ube
Neutral Position
Micro Switch
Reversing Lower
Micro Switch
PI Drive Face
Geneva Gear
Raise & Lower
T
ap Limit Switches
Figure 10.
T
ap-changer front view
.
Control Winding
T
erminal Board
Reversing Raise
Micro Switch
Holding Switch
Assembly
Drive Pinion Cam
Motor Resistor
7
9
Table of Contents
Table of Contents
1
Safety Information
2
Product Information
3
Switch Arm
5
Installation
7
Part Kit Instructions
18
QD3/T350 Main Moveable Contact Assembly Kit
19
Kit Number 5741325B04 QD3/T350 Main Moveable Contact Assembly Kit
32
QD3/T350 Motor Replacement Kit
40
Kit Number 57A63675100B
46
QD3/T350 Motor Resistor Replacement Kit
46
Kit Number 5791844A01
46
QD3/T350 PI Drive Cam Replacement Kit
49
Kit Number 5740783B21
49
QD3/T350 Reversing Stationary
51
QD3/T350 Reversing Moveable Contact and
60
Kit Number 5741325B03
60
QD3/T350 TC-LTC P.I. Drive Face Gear Kit
72
Kit Number 5740787B11
72
QD3/T350 Quick Drive Holding Switch
74
