COPES-VULCAN INSTRUCTION MANUAL
MODEL 700 DIRECT-ACTING ACTUATOR
Rev.5 (08/10) Page 2 of
20 Form 01:P224:37
TABLE OF CONTENTS
1.0 INTRODUCTION
1.1 Scope of Manual
1.2 Description of Equipment
1.3 Specifications
2.0 INSTALLATION
2.1 On Receipt
2.2 Actuator Mounting
2.3 Stem Connector and Travel Adjustment
2.4 Spring Adjustment
2.5 Air Connection
3.0 MAINTENANCE
3.1 General
3.2 Precautions
3.3 Direct-Acting Actuator
3.4 Top-Mounted Handwheel Assembly
3.5 Adjustable Up/Down Travel Stops
3.6 Fixed Travel Stops
3.7 Side-Mounted Handwheel Assembly
FIGURES
1 Exploded View of Direct-Acting Series 700 Actuator Assembly
2 Exploded View of Top-Mounted Handwheel Assembly
3 Exploded View of Side-Mounted Handwheel Assembly
4 Exploded View of Adjustable Up/Down Travel Stop Assembly
