3
WARNING : Do not cover/hold the built-in antenna part of the transmitter by your hand during
running. Do not put any conductive plate/sticker on the antenna part. Otherwise, the
operating range may become shorter.
Antenna (Built-in)
Steering Wheel
Throttle Trigger
Battery Tray
Turn model to left or right.
Control the speed of the model and
movement forward and backward.
Battery location.
ON/OFF Switch
LED Indicator
Function Button
Speed Mode / Servo Reverse
Steering Trim
Adjusts the steering in small incre-
ments so the model will run straight.
Steering Dual Rate (D/R)
Adjust the steering travel across the
entire range.
For Servo Reversing & Binding.
1 = 50% • 2 = 100%
TRANSMITTER
