STEERING
SERVO
RECEIVER
ESC
BATTERY
4
LED indicator
Antenna:
Never shorten the antenna.
Install the antenna as far as possible outside the receiver box.
Channel 3
Battery
Channel 2
Throttle
Channel 1
Steering
Install the Receiver in your model using double-sided Velcro. Velcro will hold the receiver in place and protect it from
vibrations. Mount the antenna up and away from the vehicle in an antenna tube. The higher up the antenna is, the better
signal it will receive.
Install and connect the receiver, servos and other components in accordance with the “Assembly Precautions”.
CONNECTION WITH A CONTROLLER
RECEIVER
RECEIVER CONNECTION
