Corally CT2S - Battery Installation;Replacement; Transmitter Functions

A
B
5
Slide RIGHT to turn ON the transmitter
SOLID Light = OK
FLASHING Light = Low Voltage (Replace batteries)
ON/OFF SWITCH
SERVO REVERSE
LED Status
Remove the cover and insert 4 AA size batteries.
Observe the polarity markings and insert accordingly. Power ON the transmitter and check the Led status.
Battery Voltage LED - SOLID Light = OK
Battery Voltage LED - FLASHING Light = Low Voltage (Replace batteries)
Respect the polarity markings
ST.REV (Steering Reverse) :This function reverses the
rotation direction of the STEERING servo.
Set the button to position 1 and press the FN button for
5sec to reverse direction.
TH.REV (Throttle Reverse) :This function reverses the
rotation direction of the THROTTLE servo.
Set the button to position 2 and press the FN button for
5sec to reverse the GAS.
TRANSMITTER FUNCTIONS
BATTERY INSTALLATION / REPLACEMENT
