POWER ON/OFF WARNING FUNCTION
POWER ON/OFF WARNING FUNCTION
Programmable Items Parameter Values
Basic Setting Option 1 Option 2 Option 3 Option 4 Option 5 Option 6 Option 7 Option 8 Option 9
1.Running Mode Fwd/Br Fwd/Rev/Br
2. LiPo Cells
Auto
Calculation
2S 3S 4S 6S 8S
3. Cutoff Voltage Disabled Auto (Low)
Auto
(Intermediate)
Auto (High)
4. ESC Thermal Protection 105°C/221°F 125°C/257°F
5. Motor Thermal Protection Disabled 105°C/221°F 125°C/257°F
6. Motor Rotation CCW CW
7. BEC Voltage 6.0V 7.4V
8. Brake Force 12.5% 25% 37.5% 50% 62.5% 75% 87.5% 100% Disabled
9. Reverse Force 25% 50%
10. Start Mode (Punch) Level 1 Level 2 Level 3 Level 4 Level 5
Advanced Setting
11. Drag Brake 0% 2% 4% 6% 8% 10% 12% 14% 16%
1. Power ON/OFF:
Start with the ESC turned OFF ; Press the ON/OFF button to turn ON the ESC;
Start with the ESC turned ON ; Press and hold the ON/OFF button to turn OFF the ESC.
2. Warning Tones:
Turn ON the ESC (that is to turn it ON without holding the SET button); the motor will beep the number of LiPo cells
you have plugged in. For example, 2 beeps indicate a 2S LiPo battery, 3 beeps indicate a 3S LiPo battery.
1. RUNNING MODE
Option 1: Forward + Brake
It has forward and brake functions only, no reverse and this is usually a racing mode.
Option 2: Forward + Reverse + Brake
This mode can be used as for training and it has “Forward/ Reverse with Brake” mode. This ESC uses the “DOUBLE
CLICK” method, i.e. the rst time you push the throttle/brake trigger forward to the brake/reverse position the vehi-
cle only brakes. Only when the vehicle has stopped and the engine is no longer turning is it possible to reverse the
vehicle by pressing the throttle/brake trigger again. The reverse function will not work if your car does not come to
a complete stop. The vehicle only reverses after the motor stops. This method is for preventing vehicle from being
accidentally reversed.
2. LIPO CELLS
We recommend to set this function manually instead of the “Auto Calc“ default setting. (which means calculating the
LiPo cells a utomatically)”. The ESC can only identify 3S, 4S, 6S and 8S LiPo packs when setting this item to “Auto
Calc.”. After you power ON the ESC, if the battery voltage is below 13.6V, it will be identied as a 3S, if the voltage is
from 13.6V to 17.6V, it will be identied as a 4S, if the voltage is from 17.6V to 26.5V, it will be identied as a 6S, if the
voltage is above 26.5V , it will be identied as a 8S.
Please note :
This ESC doesn’t work with 2S LiPo battery.
If you use a NiMH pack or a 5S/7S LiPo you need to set “LiPo Cells to Auto Calc.” and “Cutoff Voltage to Disabled”
3. CUTOFF VOLTAGE
Sets the voltage at which the ESC lowers or removes power to the motor in order to either keep the battery at a safe
minimum voltage (for LiPo batteries). The ESC monitors the battery voltage all the time, it will immediately reduce
the power to 50% and cut off the output 10 seconds later when the voltage goes below the cutoff threshold. The
RED LED will ash a short, single ash that repeats (☆☆☆) to indicate the low-voltage cutoff protection is activated.
Please set the “Cutoff Voltage” to “Disabled” if you are using NiMH batteries.
Option 1: Disabled
The ESC does not cut the power off due to low voltage. We do not recommend using this option when you use any LiPo
battery as you will irreversibly damage the product. You need to select this option when you are using a NiMH pack.
Option 2: Auto (Low)
Low cutoff voltage, difculty to get the LVC Protection activated, is applicable to batteries with poor discharge capability.
