Core CGT 400 Service Guide

HARDWAREREQUIRED:
‐(2)10‐321”BOLTS
‐(2)10‐321¼“BOLTS
‐(4)10‐325/16NUT
MOTOR‐ 400SERIES
TOOLSREQUIRED:
ELECTRIC‐SCREWGUN‐T25BIT
5/16”NUT‐DRIVER
NEEDLENOSEPLIERS
1. Attachthehallwireconnection.Thenattachthephasewires
startingfromthehallconnection,orange,yellow,blue.
2. Attachtheyok etothemotorwiththe1‐1/4”
boltsclosesttothemotor,andthe1”boltsunderneath.
The10‐32x 5/16”nutsareplacedonthebottomsideof
themotor.
3.Reverseyourinstructionsonpage12toreassembletheunit.
MotorReplacement
1.
2.
