Core CGT 400 Service Guide

HARDWAREREQUIRED:
‐BUMPHEAD
‐WEEDWRAP
‐2WEEDWRAPWASHERS
‐(2)8‐321”BOLT
‐(2)8‐32LOCKNUTS
‐(2)10‐32LOCKNUTS
‐STRINGGUARD
TOOLSREQUIRED:
ELECTRICSCREWGUN‐T‐20BIT
ANDT‐25BIT
3/8”AND11/32”NUT‐DRIVERS
1. SpinBumphead clockwise
whileusinganinserttoolin
thecatch‐hole.(i.e.drillbit)
2. Removeblackweedwrap.
3. Remove2washersfrom
shaft.
4. Remove3/8”locknutsfrom
shield.
5. RemoveBoltsfromtheside
oftheshield,undertheyoke.
3.
4.
5.
MotorDisassembly
1.
2.
