Series 100
6
piston;
• slowly lower the unit with the motor off until the
correct fit of the device is obtained.
Afterwards remove the device and put it back in its slot.
1.6.2. BLOCKING THE FOOTREST
The drive footrest must always be blocked in position
to impede its accidental movement, by using the safety pin
“B” (see fig.2).
Introduce pin “B” into hole “1” to block the footrest in the
raised position;
Introduce pin “B” in hole “2” to block the footrest in the
lowered position;
fig. 2 – Safety Devices
1.7. ACCESSORIES
READ CAREFULLY: Read the
and the mode of use for the accessories that
have been installed on your machine carefully.
Refer to the instruction manual that was
provided with them.
The machine is furnished with equippment to make it
