Linus
22
11. Technical Data and Pictorial Representation
Linus 25 Linus 40 Linus 60 Linus 80 Linus 120
Output capacity
continuously - liter per hour 25 38 64 90 120
Refrigerant R 134a in kg 0,140 0,205 0,200 0,300 0,610
Supply voltage 230V/50Hz
Power consumption in watt 190 240 495 610 750
Compressor output in watt* 280 420 628 925 1269
Cooling
in watt 291 450 744 1106 1400
in kcal/h 250 388 640 951 1204
Number of cooling coils
Bier 1 1 1 or 2 2 2
Dimensions in mm
Height 413 385 440 430 430
Width 326 395 426 535 580
Depth 405 310 320 346 380
Shipping weight in kg 24 27 37 /40 45 48
* at 0°C evaporation temperature
Cooling capacities and output capacity at 24°C ambient temperatures and beverage inlet temperatures of 18°C
and beverage outlet temperatures of less than 8°C.
We reserve the right to make modifications.
Linus single valve overcounter Linus double valve overcounter
!
