New 3200-992
February, 2011
Cornell Pump Company
CUTTER MODIFICATION KIT
REMOVAL, ASSEMBLY, AND ADJUSTMENT INSTRUCTIONS
MODELS 6NHTA, 6NHTB
WARNING
Rotating cutter ring, stationary cutter plate, and rotating assembly have VERY SHARP edges. DO
NOT place body parts in pump inlet or clean-outs at any time. Wear protective gloves when
working on assembly.
Figure 1. Cutter Modification Kit Assembly
