SEVERAL THREAD WORKS
Accessories are mounted on weaving gear C.10294 and are marked A & C , as
well as on the gear. (Fig. 11)
Two threads works are made by braid curling around the chainstitch row which
sews it on the cloth.
Three threads works are made with additional stuffing between coiling and chain
stitch.
a.Two threads works
Use the following parts :
- Spoolholder C.10632W mounted on the weaving gear C.10294
- Weaver C.10300W
- Nipple C.00601C...for 2 threads screwed in lower tube (according
thickness)
(Fig. 11).
The thread comes from spool C.00635M, passes through the hole of the weaver
holder C.10302 through the eyelet C.00619 then into the thread guide C.10304/1.7
or C.10304/3, according to the thickness.
Let the lace pass under the pressure foot. The thread tension is adjusted by the
screw which is under the spoolholder.
The weaver height settings will be made when the machine is disclutched and the
nipple is in upper position. Release the weaver assembly holding screw and set
the lining with lower part of nipple.
Since in two threads works, the chain stitch is completely coated by the coiling
thread, machine must be set with a rather short stitch.
b.Three threads works
Use the following parts :
- Spoolholder C.10632W complete
- Weaver C.10300W complete
- Nipple C.01127A… for three threads, size according to cord
thickness
- Braiding attachment C.10288W complete
(Fig. 10 & 11)
Same works as with two threads, plus a “Stuffing” thread which must come through
the hook needle holder. It is better to use a rather flexible material.
Put the crank towards the operator, the stuffing thread passage hole must be on
the opposite side. The hook needle will be screwed so that its hook will be on the
opposite side of the flat part of the needle holder. The coiling thread comes from
spool C.00635M and passes through holes. Follow the instructions as for 2
threads. The stuffing thread comes from the braiding attachment C.10288W
complete and passes through the needle holder and the guide and comes upon
material. The hook needle is set rather close to the material to obtain a short chain
stitch.
