Cors-Air BLACK DEVIL PRO - Main Torques

MAIN TORQUES
W W W . C O R S A I R M O T O R S . C O M
I N F O @ C O R S A I R M O T O R S . C O M
6
MAIN TORQUES Kg. m (Nm)
N
UTS TO FIX THE HEAD 2,5 25
N
UTS TO FIX HALF-CRANKCASE 2,5 25
B
OLTS TO FIX THE BACK FLANGE TO THE
CRANKCASE
2,0 20
N
UTS TO FIX THE PINION TO THE FRONT
PART
OF THE DRIVE SHAFT
4,5 45
N
UTS TO FIX BACK PART OF DRIVE SHAFT
TO
IGNITION
HANDWHEEL
3,5 35
G
AP BETWEEN COIL AND HANDWHEEL 0,4 mm
IMPORTANT: remember that the battery of the electric start should be recharged before
starting the engine.
In case LiPo batteries are used, detach the recharge wire (yellow) and follow all safety
precautions for LiPo batteries use.
