Corsair 750D User Manual





 
> Remove thumbscrews and corresponding slot cover(s).
> Install the add-on card and secure with thumbscrews.
Installing the PCI-E/PCI cardsInstalling the power supply (PSU)
> Seat the PSU on the bottom of the case.
> Align holes and secure the PSU with screws.
Note: PSU can be installed in either fan up or fan down orientations.

Corsair 750D Specifications

General

Type	Full Tower
Material	Steel, Plastic
Expansion Slots	9
Weight	9.7 kg
Maximum GPU Length	450mm
Maximum CPU Cooler Height	170mm
Maximum PSU Length	225mm
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Dimensions	560mm x 546mm
Drive Bays	3 x 5.25"
Cooling Support	Front: 2 x 140mm or 3 x 120mm, Top: 3 x 120mm or 2 x 140mm, Rear: 1 x 140mm or 120mm, Bottom: 2 x 120mm
Included Fans	Front: 2 x 140mm, Rear: 1 x 140mm
Radiator Support	Top: 120/240/280/360mm; Rear: 120/140mm
Front I/O Ports	2 x USB 3.0, Audio in/out
