Corsair 750D User Manual





Installing a 5.25" drive/devices (ODD)
> Remove the front panel 5.25" drive bay cover.
> Insert the ODD into the drive bay until the tool-free
latch clicks, securing the drive.
> To remove, push the tool-free tab to release
the ODD drive and remove.

Corsair 750D Specifications

General

Type	Full Tower
Material	Steel, Plastic
Expansion Slots	9
Weight	9.7 kg
Maximum GPU Length	450mm
Maximum CPU Cooler Height	170mm
Maximum PSU Length	225mm
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Dimensions	560mm x 546mm
Drive Bays	3 x 5.25"
Cooling Support	Front: 2 x 140mm or 3 x 120mm, Top: 3 x 120mm or 2 x 140mm, Rear: 1 x 140mm or 120mm, Bottom: 2 x 120mm
Included Fans	Front: 2 x 140mm, Rear: 1 x 140mm
Radiator Support	Top: 120/240/280/360mm; Rear: 120/140mm
Front I/O Ports	2 x USB 3.0, Audio in/out
