Corsair AX Series User Manual

4
AX SERIES
™
Congratulations on the purchase of your new Corsair AX Series High Performance
ATX power supply.
The Corsair AX series is quiet, powerful, and is certified 80 PLUS® Platinum, for up to
92% eciency.
Product Features
80 PLUS® Platinum Eciency
The AX series is 80 PLUS® Platinum certified, for up to 92% eciency. This means less power
drawn from the wall, less heat generated, and lower electricity bills.
Fanless operation at Low Loads
The AX series is so ecient that the temperature-controlled ball-bearing fan doesn’t even spin up
at low loads. As the load rises, the fan will spin as needed.
Fully modular cables
Fully modular means easy installation. Plug the cables into your hardware first, then route them
down to the PSU area of your case for easy, quick, clean cable routing.
Reliable, continuous power
Rated at a server-like 50C, the AX series features industrial grade components and specifications,
painstakingly managed by Corsair engineers to guarantee its industry-leading seven year
warranty.
Oustanding Compatibility
Regardless of your system layout, the AX series features long cables and plenty of connectors to
run just about anything you need. PSU located on the bottom of your case? Don’t worry, in most
cases, the cables should reach easily.
User-selectable fan mode switch
If you don’t need fanless operation, , ip the switch. The [OTHER] mode oers standard operation
where the fan is turned on full time. Don’t worry, though. It’s still thermally controlled, so it’s not
running at full speed all the time.
Power Supply Specifications
• 150mm(W) x 86mm(H) x 160mm(L)
• MTBF: 100,000 Hours
Package Contents
• Corsair AX Series power supply unit
• Modular cable set
• User Manual
• AC power cord
• Cable ties
• Mounting screws
• Corsair case badge
• Carrying bag
