Corsair AX1200 User Manual

7
PROFESSIONAL SERIES GOLD
Power supply specifications
• Dimensions:
- AX750/850: 5.9”(W) x 3.4”(H) X 6.3”(L); 150mm(W) x 86mm(H) x 160mm(L)
- AX1200: 5.9”(W) x 3.4”(H) X 7.3”(L); 150mm(W) x 86mm(H) x 200mm(L)
• MTBF: 100,000 Hours
MODEL CMPSU-750AX CMPSU-850AX CMPSU-1200AX
AC INPUT RATING
AC INPUT
90-264V
INPUT CURRENT
9-4.5A 10-5A 15A
FREQUENCY
50/60Hz
DC OUTPUT RATING
MAX.
LOAD
MAX.
OUTPUT
MAX.
LOAD
MAX.
OUTPUT
MAX.
LOAD
MAX.
OUTPUT
+3.3V
25A 125W 25A 125W 30A 180W
+5V
25A 25A 30A
+12V
62A 744W 70A 840W 100.4A 1204.8W
-12V
0.5A 6W 0.5A 6W 0.8A 9.6W
+5VSB
3A 15W 3A 15W 3.5A 17.5W
TOTAL POWER 750W 850W 1204.8W
Package contents
• Corsair Professional Series Gold power supply unit
• Modular cable set
• User Manual
• AC power cord
• Cable ties
• Mounting screws
• Corsair case badge
• Carrying bag
Corsair cable configuration
CMPSU-750AX
QTY LENGTH CONNECTOR/CABLE
1 600mm 1
ATX CABLE (24-PIN)
2 600mm 1
EPS12V CPU CABLE (8-PIN)
2 600mm 2
PCI-E CABLE
2 850mm 4
SATA CABLE
2 600mm 2
2 850mm 4
PERIPHERIAL CABLE
2 101mm 1
FLOPPY ADAPTER

Corsair AX1200 Specifications

General

Wattage	1200W
Efficiency	80 PLUS Gold
Modular	Full
Form Factor	ATX
Dimensions	150mm x 86mm x 200mm
ATX Version	ATX12V v2.31
PCIe Connectors	8x 6+2-Pin
SATA Connectors	16
Molex Connectors	8
Input Voltage	100-240V
Cooling	140mm fan
EPS Connectors	2x 8-pin
Input Frequency	50Hz - 60Hz
