11. Installing the Front I/O Connectors9. Installing a Second Front Fan
10. Powering the Case Fans
After locating your 3 or 4
pin fan headers on your
motherboard (see your
motherboard’s manual for fan
header locations), plug in the
included fan cable.
See your motherboard’s
manual for front panel header
locations and pin-outs.
USB 3.0
HD AUDIO RESET SW
POWER LED +
POWER LED –POWER
SW
HDD LED
To install an additional 120mm
or 140mm fan, unscrew the
top fan then slide it down to
the mounting points below.
