CARBIDE SERIES
®
SPEC-M2
109
ENGLISH
4. Installing the Power Supply
3. Installing PCI-E/PCI Card(s)
2. Installing the Motherboard
1. Removing the Side Panels
Simply remove the
thumbscrews then slide the
side panels back and out.
Note: Corsair recommends
removing both side panels and
setting them aside when building
your system to avoid accidental
damage. Both side panels are
interchangeable and should be
removed to reduce clutter.
Remove slot cover, install
expansion card, and secure
with screw(s) as necessary.
Position the PSU on the
bottom of the case then align
the case holes and secure the
PSU with screws provided with
your power supply.
First, install your
motherboard’s I/O shield
(see your motherboard’s
manual for guidance).
Align your motherboard with
the pre-installed standos.
Use the provided screws
to secure the
motherboard to the
motherboard tray.
