ENGLISH
4
ENGLISH
DESCRIPTION QTY
CONNECTORS TOTAL LENGTH 750W 850W 1000W
ATX Cable (24-pin)
610mm ± 10mm 1 1 1
EPS/ATX12V Cable (8-pin) (4+4)
650mm ± 10mm 2 2 2
PCIe Cable (8-pin) (6+2)
750mm ± 10mm 1 1 2
PCIe Cable (8-pin) (6+2 split)
600mm ± 10mm 1 1 2
SATA Cable (3 SATA)
700mm ± 10mm 1 1 1
SATA Cable (4 SATA)
800mm ± 10mm 1 1 1
Peripheral Cable (4 PATA)
750mm ± 10mm 1 1 1
CORSAIR RMe SERIES CABLE INFORMATION

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Corsair RM1000e and is the answer not in the manual?

Corsair RM1000e Specifications

General IconGeneral
Wattage1000W
Efficiency Rating80 PLUS Gold
ModularFully Modular
Form FactorATX
Fan Size140mm
Zero RPM ModeYes
MTBF100, 000 hours
EPS Connectors2
PCIe Connectors6
ATX Connector1
Fan BearingFluid Dynamic Bearing
Input Voltage100-240V
Input Frequency47-63Hz
Output+3.3V@20A, +5V@20A, +12V@83.3A, -12V@0.3A, +5Vsb@3A
Dimensions150mm x 86mm x 160mm
Operating Temperature0°C to 50°C
Fan Bearing TypeFluid Dynamic Bearing
Connectors1 x ATX, 2 x EPS, 6 x PCIe, 4 x Peripheral
ProtectionsOVP (Over Voltage Protection), UVP (Under Voltage Protection), SCP (Short Circuit Protection), OTP (Over Temperature Protection), OPP (Over Power Protection)
