Corsair RM850e User Manual

ENGLISH
4
ENGLISH
DESCRIPTION QTY
CONNECTORS TOTAL LENGTH 750W 850W 1000W
ATX Cable (24-pin)
610mm ± 10mm 1 1 1
EPS/ATX12V Cable (8-pin) (4+4)
650mm ± 10mm 2 2 2
PCIe Cable (8-pin) (6+2)
750mm ± 10mm 1 1 2
PCIe Cable (8-pin) (6+2 split)
600mm ± 10mm 1 1 2
SATA Cable (3 SATA)
700mm ± 10mm 1 1 1
SATA Cable (4 SATA)
800mm ± 10mm 1 1 1
Peripheral Cable (4 PATA)
750mm ± 10mm 1 1 1
CORSAIR RMe SERIES CABLE INFORMATION

Corsair RM850e Specifications

General

Wattage	850W
Efficiency Rating	80 PLUS Gold
Modular	Fully Modular
Form Factor	ATX
Fan Size	120mm
Zero RPM Mode	Yes
Fan Bearing Type	Fluid Dynamic Bearing
EPS 4+4 Pin Connectors	2
Molex 4-Pin Connectors	4
