Corsair RMe Series User Manual

ENGLISH
3
ENGLISH
Dimensions: 140mm(L) x 150mm(W) x 86mm(H)
Package Contents: Power Supply, AC Cable, DC Cables, Cable Ties, Mounting Screws, Safety Leaflet
RM1000e INCLUDED HARDWARE AND SPECIFICATIONS
CORSAIR RM1000e POWER SUPPLY EFFICIENCY
10021050
20
95
90
85
80
75
70
EFFICIENCY (%)
SYSTEM LOAD (%)
CORSAIR RM1000e POWER SUPPLY FAN NOISE CURVE
0
1000
200 400 600 800
30
25
20
15
10
5
0
FAN NOISE (dB)
POWER OUTPUT (W)
CORSAIR RM1000e POWER TABLE MAX LOAD MAX OUTPUT
MODEL RPS0158 +3.3V 20A
150W
PART NO. 75-005037 +5V 20A
AC INPUT RATING 100 - 240V a.c. +12V 83.5A 1000W
INPUT CURRENT 12 - 6A -12V 0.3A 3.6W
FREQUENCY 47 - 63Hz +5Vsb 3A 15W
TOTAL POWER: 1000W
input 115V a.c.
input 230V a.c.

Corsair RMe Series Specifications

General

Efficiency Rating	80 PLUS Gold
Modular	Fully Modular
ATX Version	ATX 3.0
Zero RPM Mode	Yes
Form Factor	ATX
Dimensions	150mm x 86mm x 140mm
Protection Features	OCP, OVP, UVP, SCP, OTP
Wattage Options	750W, 850W, 1000W
