13ASSEMBLY INSTRUCTIONS |
STEP 6
1. Secure 4x part 19 to parts 4 and 5, and
secure with:
- 4x part 79
- 4x part 85
2. Attach part 44 onto part 19 as pictured and
place the collars part 46 into part 44.
3. Secure part 15 onto either post part 4 or 5 using:
- 2x part 74
- 1x part 22
- 2x part 83
- 4x part 85
85
83
74
79
M10 x 70mm Φ 10
M10 x 15mm M10
2pcs 8pcs
4pcs 2pcs
83
22
74
85
85
15
19
85
79
46
44
