19ASSEMBLY INSTRUCTIONS |
STEP 12
1. Secure part 32 onto part 7 and 8 using:
- 20x part 79
- 20x part 85
2. Attach part 20 to part 88, then connect part 88
with part 50 onto part 21, in order as shown.
3. Repeat step 2 for the other side.
4. Secure part 31 to part 30 for using:
- 2x part 80
- 2x part 83
- 4x part 85
85
83
80
79
M10 x 110mm Φ 10
M10 x 15mm M10
2pcs 24pcs
20pcs 2pcs
31
31
80
32
85
79
20
50
88
85
83
To Next Page
