Forward-Facing Child Fit
8
Rear-Facing Child Fit
7
Need to make adjustments?
To change headrest/harness height, see page 9.
To change buckle position, see pages 15-16.
Need to make adjustments?
To change headrest/harness height, see page 9.
To change buckle position, see pages 15-16.
Harness Strap Position
The harness strap must be at or
slightly above your child’s shoulders;
never below.
Max Seated Shoulder Height
In this car seat, the maximum seated
shoulder height is 17 in. (43.2 cm).
To measure your child’s seated
shoulder height: have them sit on
the fl oor with their back fl at against a
wall. Then measure from the fl oor up
to the top of their shoulder.
Buckle Position
The buckle can be used in any buckle
slot.
Choose the slot closest to your child.
The buckle should not be
underneath or behind your child.
Head Position
The tops of your child’s ears must
be below the top of the car seat’s
headrest.
Harness Strap Position
The harness strap must be at or
slightly below your child’s shoulders;
never above.
Buckle Position
The buckle must be used in either
the 1st or 2nd buckle slot.
Choose the slot closest to your child.
The buckle should not be
underneath or behind your child.
Head Position
The top of your child’s head must be
at least 1 in. (2.5 cm) below the top
of the car seat’s headrest.
Do not use 3rd slot in
Rear-Facing Mode.
Max Seated
Height
17 in.
(43.2 cm)
