9. SPREADING CHARTS
9.1. SPREADING CHART AND STANDARD LIMITER SPREADING
ADJUSTMENT
ADJUSTMENT D in mm. SPREADING WIDTH
mm.40 160 mm
mm.50 240 mm
mm.60 480 mm
mm.100 Open
APERTURA LEVA
SPANDICONCIME
QT.Kg/metro a
velocita 6 km
QT.Kg/metro a
velocita 8 km
QT.Kg/metro a
velocita 12 km
4 0,148(148 for Km) 0,111(111 for Km) 0,74(74 for Km)
6 0,576(576 for Km) 0,432(432 for Km) 0,288(288 for Km)
8 0,984(984 for Km) 0,738(738 for Km) 0,492(492 for Km)
